Industries We Serve

Landfill

Tighter EPA restrictions require Landfills to extract methane gas naturally generated by landfills and use it for energy generation. Our drill rigs are the best machine in the market to drill your well. The EK160 and EK125 are market leaders in this sector due to the easy mobilization (one load) and the 200ft depth that they can achieve.

Standard Chassis: CAT 323 Next Gen
Installed Power: 164 hp 122 kW
Maximum Torque: 101,700 ft.lbs 14,000 kg.m
Maximum Diameter: 8 ft 2,440 mm
Maximum Drilling Depth: 155 ft 47,300 mm
Operation Weight 85,000 lb 38,600 kg
Standard Chassis: CAT 336 Tier IV
Installed Power: 314 hp 234 kW
Maximum Torque: 193,360 ft.lbs 26,700 kg.m
Maximum Diameter: 11 ft 3,350 mm
Maximum Drilling Depth: 200 ft 61,000 mm
Operation Weight: 145,000 lb 65,900 kg
Standard Chassis: CAT 330 Next Gen
Installed Power: 275 hp 205 kW
Maximum Torque: 155,100 ft.lbs 21,500 kg.m
Maximum Diameter: 10 ft 3,050 mm
Maximum Drilling Depth: 200 ft 61,000 mm
Operation Weight: 110,000 lb 50,000 kg
Standard Chassis: CAT 336 Next Gen
Installed Power: 314 hp 234 kW
Maximum Torque: 209,000 ft.lbs 29,000 kg.m
Maximum Diameter: 13 ft 4,000 mm
Maximum Depth: 260 ft 79,300 mm
Operation Weight: 185,000 lb 84,000 kg

CZM USA is a specialized foundation equipment manufacturer headquartered in Savannah, GA.
